Product information
- Category: Hydraulic Orbital Motors
- Brand: M+S
- Model: MS
- Product Type: LSHT Medium Duty
- Product Catalog: Download Catalog
Medium Duty Orbital Motor MS
Orbit motors convert hydraulic energy (pressure, oil flow) into mechanical energy (torque, speed). Hydraulic orbit motors operate on the principle of an internal gear (rotor) rotating within a fixed external gear (stator). The internal gear transmits the torque generated by the application of pressure from hydraulic oil fed into motor which is then delivered via the motor's output shaft. Orbit motors have high starting torque and constant output torque at wide speed range
Application
Conveyors
Metal working machines
Agricultural machines
Mining machinery
Road building machines
Food industries
Special vehicles etc.
Option
Model - Spool valve, gerotor
Flange and wheel mount
Short motor
Motor with Drum Brake
Speed sensoring
Side and rear ports
Shafts - straight, splined and tappered
SAE, Metric and BSPP ports
Other special features
| Code |
Displacement [cm3/rev] |
Max. speed [RPM] |
Max. Torgue [daNm] |
Max. Output [kW] |
Max. Pressure Drop [bar] |
Max. Oil Flow [Ipm] |
|||||
| cont. | int* | cont. | int* | cont. | int* | cont. | int* | cont. | int* | ||
| MS 80 | 80,5 | 810 | 1000 | 24 | 31 | 15,5 | 19,5 | 210 | 275 | 65 | 80 |
| MS 100 | 100 | 750 | 900 | 30,5 | 39 | 18 | 22,8 | 210 | 275 | 75 | 90 |
| MS 125 | 125,7 | 600 | 720 | 37,5 | 49 | 18 | 22,5 | 210 | 275 | 75 | 90 |
| MS 160 | 159,7 | 470 | 560 | 49 | 60 | 16,5 | 23 | 210 | 275 | 75 | 90 |
| MS 200 | 200 | 375 | 450 | 61 | 72 | 16,5 | 22 | 210 | 275 | 75 | 90 |
| MS 250 | 250 | 300 | 360 | 72 | 87 | 14,5 | 18 | 200 | 250 | 75 | 90 |
| MS 315 | 314,9 | 240 | 290 | 82,5 | 100 | 15,7 | 17 | 200 | 240 | 75 | 90 |
| MS 400 | 397 | 190 | 230 | 86,5 | 99 | 11 | 12,5 | 160 | 190 | 75 | 90 |
| MS 475 | 474,6 | 160 | 190 | 85 | 99 | 8,4 | 11,3 | 130 | 150 | 75 | 90 |
| MS 525 | 522,7 | 145 | 175 | 85 | 99 | 7,6 | 10,4 | 115 | 135 | 75 | 90 |
| MS 565 | 564,9 | 130 | 160 | 85 | 99 | 6,9 | 9,6 | 105 | 125 | 75 | 90 |
* Intermitten operation: the permissible values may occur for max. 10% of every minute.
| Pressure fluid | Mineral based- HLP(DIN 51524) or HM(ISO 6743/4) | |
| Temperature range, | °C | -40÷140 |
| Optimal Viscosity range, | mm2/s | 20÷75 |
| Filtration | ISO code 20/16 (Min. recommended fluid filtration of 25 micron ) |
